General

Standard Functions

Print, Copy, Scan, Network, Duplex
Value Added Functions

Fax, NW PC Fax
Processor

1GHz (Dual Core)
Operational Panel

7" Color Touch-Panel LCD, 800 x 480 (WVGA)
Memory (Standard)

1GB
Memory (Maximum)

1GB
Hard Disk Drive

320GB or higher (Usable Space: 88GB)
Interface (Standard)

High Speed USB 2.0 Device/Host, Ethernet 10/100/1000 BASE TX
Power Consumption

Max 1.5kW( Ready : 100W, Low power : 16W, Sleep : 1.5W )
Noise Level

Copying: 53dBA, Printing: 50dBA, Ready: 30dBA, Sleep: 27dBA
Dimension (WxDxH)

560 x 600 x 844 mm / 22.0" x 23.6" x 33.2:" (including RADF)
Weight

76 Kg / 167 lbs (including RADF)
Max. Monthly Duty Cycle

100000Pages
Network Security

SSL/TLS, IP sec, SNMPv3, IPv6, Protocol & Port Management, IP/MAC filtering
Certification

CCC(ISO15408), IEEE P2600-2008, WHQL Compliance

Speed (Mono)

30 ppm in A4/Letter
Speed (Color)

30 ppm in A4/Letter
First Print Out Time (Mono)

9 sec (From Ready Mode)
First Print Out Time (Color)

11.5 sec (From Ready Mode)
Resolution

Default : 2,400 x 600 dpi Effective Output (600 x 600 x 2 bit) / Max : 9,600 x 600 dpi effective output (600 x 600 x 4 bit), 1,200 x 1,200 dpi (Half Speed)
Print Languages

PCL5c, PCL6, Postscript 3, PDF 1.7+, XPS
Client OS Support

Windows 8 / 7 / Vista / XP / 2008R2 / 2008 / 2003, Mac OS 10.4 - 10.8, RedHat Enterprise Linux WS 4 / 5 (32/64bit), Fedora Core 2 - 10 (32/64bit), SuSE Linux 9.1 (32bit), OpenSuSE 9.2 / 9.3 / 10.0 / 10.1 / 10.2 / 10.3 / 11.0 / 11.1 (32/64bit), Mandrake 10.0 / 10.1 (32/64bit), Mandriva 2005-2009 (32/64bit), Ubuntu 6.06 / 6.10 / 7.04 / 7.10 / 8.04 / 8.10 (32/64bit), SuSE Linux Enterprise Desktop 9 / 10 (32/64bit), Debian 3.1 / 4.0 / 5.0 (32/64bit)
Direct Print Support

Jpeg,Tiff,PDF,Samsung PRN
Network Protocols

IP Management(DHCP, DHCPv6, BOOTP, AutoIP, SetIP, Static) / Discovery Protocol (SLP, UPnP, Bonjour, DNS, WINS) / Printing Protocol(TCP/IP(9100), TCP/IP(9100)v6 , LPR, LPR6 , IPP, WSD) / Management Protocol(SNMPv1.2, SNMPv1.2(IPv6), SNMP3, SNMPv3(IPv6), HTTP, HTTPs, LDAP, SMTP) / Scan Protocol(SMTP, FTP, SMB, Twain for Network) / Security Protocol(SMB, Kerberos, LDAP, IPsec)

SHOW MORE SPECS

Copy

Speed (Mono)

30 cpm in A4/Letter
Speed (Color)

30 cpm in A4/Letter
First Copy Out Time (Mono)

6.9 seconds
First Copy Out Time (Color)

8 seconds
Resolution

600 x 600 dpi
Reduce / Enlarge Range

25% - 400%
Multi Copy

9999Pages
Copy Features

ID Copy, Clone Copy, N-UP Copy, Poster Copy

Scan

Scan Speed (Mono)

45 ipm (300 dpi / A4/Letter)
Scan Speed (Color)

45 ipm (300 dpi / A4/Letter)
Compatibility

Network TWAIN
Resolution (Enhanced)

Up to 4,800 x 4,800 dpi
Scan Destinations

E-mail, USB, FTP, SMB, HDD, PC

FAX

Compatibility

ITU-T G3, Super G3
Modem Speed

33.6kbps
Resolution

Up to 600 x 600 dpi (Mono)
Memory

HDD Back-up
Auto Dial

Yes
Fax Feature

Speed Dial, Group, Dial, On-hook Dial, Auto Redial, Caller ID, Secure Reception, Fax forwarding, etc.

Paper Handling

Input Capacity (Cassette)

1040Sheets
Input Capacity (Maximum)

2,180 Sheets ( 1,140-Sheet Standard + 1,040-Sheet Optional DCF)
Input Capacity (Multipurpose Tray)

100Sheets
Input Capacity (Other Options)

520-Sheet Optional Cassette x 2
Media Type (Cassette)

Plain Paper / Thin Paper / Bond / Punched / Pre-Printed / Recycled / Label / CardStock / Letterhead / Thick / Cotton / Colored / Archive / Glossy
Media Type (Multipurpose Tray)

Printer Default / Plain Paper / Thick Paper / Thin Paper / Bond Paper / Color Paper / CardStock / Labels / Envelope / Preprinted / Letterhead / Recycled Paper / Cotton / Archive / Glossy
Media Type (Other Options)

Plain Paper / Thin Paper / Bond / Punched / Pre-Printed / Recycled / Label / CardStock / Letterhead / Thick / Cotton / Colored / Archive / Glossy
Media Size (Cassette)

Cassette 1: 148 x 210 mm ~ 297 x 354 mm (5.8" x 8.2" ~ 11.7" x 14") / Cassette 2: 148 x 210 mm ~ 297 x 432 mm (5.8" x 8.2" ~ 11.7" x 17")
Media Size (Multipurpose Tray)

98 x 148 mm ~ 297 x 432 mm (3.8" x 5.8" ~ 11.7" x 17")
Media Size (Other Options)

148 x 210 mm ~ 297 x 432 mm (5.8" x 8.2" ~ 11.7" x 17")
Media Weights (Cassette)

Plain Paper: 71~90g/㎡(21~24 lb), (Duplex : 20~24lb) / Thick Paper: 91~105g/㎡(25~28 lb), (Duplex : 25~28lb) / Heavy Weight 1 Paper : 106~120g/㎡ / Heavy Weight 2 Paper : 121~175g/㎡ / Extra Heavy Weight 1 Paper : 176 ~ 216g/㎡ / Thin Paper: 60~70g/㎡ (16~19 lb) / Bond Paper: 105~120g/㎡ (28~32 lb) / Punched Paper: 71~90g/㎡ (19~24 lb) / Pre-Printed : 71~90g/㎡ (19~24 lb) / Recycled : 60~90g/㎡ (16~24 lb) / CardStock : 105~163g/㎡ (28~43lb) / Letterhead : 71~90g/㎡ (19~24 lb) / Cotton paper : 75~90g/㎡ (20~24 lb) / Label : 120~150g/㎡ (32~40 lb)
Media Weights (Multipurpose Tray)

16~47lb (60 to 176g/㎡) ( Simplex, Duplex )
Media Weights (Other Options)

Plain Paper: 71~90g/㎡(21~24 lb), (Duplex : 20~24lb) / Thick Paper: 91~105g/㎡(25~28 lb), (Duplex : 25~28lb) / Heavy Weight 1 Paper : 106~120g/㎡ / Heavy Weight 2 Paper : 121~175g/㎡ / Extra Heavy Weight 1 Paper : 176 ~ 216g/㎡ / Thin Paper: 60~70g/㎡ (16~19 lb) / Bond Paper: 105~120g/㎡ (28~32 lb) / Punched Paper: 71~90g/㎡ (19~24 lb) / Pre-Printed : 71~90g/㎡ (19~24 lb) / Recycled : 60~90g/㎡ (16~24 lb) / CardStock : 105~163g/㎡ (28~43lb) / Letterhead : 71~90g/㎡ (19~24 lb) / Cotton paper : 75~90g/㎡ (20~24 lb) / Label : 120~150g/㎡ (32~40 lb)
ADF Type

RADF
ADF Document Capacity

100Sheets

Supplies

Toner (Black)

20,000 pages (5% Coverage)
Toner (Color)

15,000 pages (5% Coverage)
Imaging Unit/Drum (Black)

50,000 pages (5% Coverage)
Imaging Unit/Drum (Color)

50,000 pages (5% Coverage)
Waste Toner Container

Approx. 26,300 pages (5% Coverage)

Option

Option

Cabinet Stand, Dual Cassette Feeder, Job Separator, Inner Finisher, Fax Kit, FDI Kit, Working Table, SmarThru Workflow, CounThru

Solution

Device Management

Yes
Output Management

Yes
Document Management and Distribution

Yes
Security

Yes

Mobility

Yes

*Term and Conditions apply

Term and Conditions(Purchases)

One Year Warranty Or 10'000 Copies Which Is Come First
Warranty Main Board,IC Board ,Hard disk Only
Not Include Consumable parts like toner,Drum and Feed Roller,Fusing Unit,toner Hopper

Purchase =Warranty 1 years or 10'000 copies

(Warranty up to 3 year please call for enquiry)
