Product Description
Invengo's XC-RF861 is a compact UHF RFID reader that delivers excellent performance at an incredible value. The reader has a sleek design and is easy to install. The XC-RF861 is Linux based, combining reliable reading with ease of programming and communication. It is suitable for applications in asset tracking, inventory management, and track and trace. What's Included? Invengo XC-RF861 UHF RFID Reader Unit, RS-232 Cable, Ethernet Cable, a One Year Factory Warranty, Free Application Software (Contact Us), and a Mounting Bracket. SPECIFICATIONS ELECTRICAL: Air Interface Protocol: EPCglobal UHF Class 1 Gen 2 (ISO 18000-6C) Operating Frequency: US (902-928 MHz), EU (865-868 MHz) Transmit Power: 9.0 to 30 dBm Max Receive Power: Not Published Max Read Distance: Not Published Max Read Rate: Not Published Data Interface: RS-232, Ethernet GPIO: 2 Isolated inputs, 2 Isolated outputs, 2 Relay outputs Power Source: IEEE802.3at PoE; Power Supply and Cord not included MECHANICAL: Antenna Ports: 4 RP-TNC Female ports Dimensions: 7.8 x 6.9 x 1.5 in (196 x 176 x 38 mm) Weight: 2.20 lbs (997.9 g) ENVIRONMENT: IP Rating: IP 53 Operating Temperature: -20° to 70° C APPLICATION INTERFACE: Host API: JAVA, .NET, C Demo Software: Invengo RFID Demo Software Application Software: Invengo ConneXion
