3D HDMI HD Video Capture Card
























Introduction
1. With this REL011 (M) HD Video Capture, you can capture 1080P video from HDMI or YPbPr(Component Video) port, such as blue ray DVD, set-top-box, computer, game box, etc.
2. REL011 support HDCP protocol.
3. With Remote Controller (Power by 1 x CR2025 button battery).

Features/ports and buttons
1. OUTPUT: HDMI output, pass through display HDMI or YPbPr video.
2. INPUT: HDMI input.
3. YPBPR INPUT: YPbPr component input.
4. PWR: DC 5V power supply.
5. USB HOST: For plug USB flash drive or USB HDD for saving record files.
6. LINE IN: Work with YPbPr input only.
7. MIC: For connect a microphone and record voice comments when play game ( REL011 only work with YPbPr component input. HDMI input not support MIC record)
8. LINE OUT: Audio output.
9. LED indicator: Color be green when standby, be red when recording.
10. REC button: Press to record/stop.
11. IR - REC button: Press to record/stop.

Specification:
General
Model REL011
Interface 1 x USB 2.0
DC 5V
YPbPr
1 x HDMI In
1 x HDMI Out
3 x LINE (IN & OUT & MIC)
Power DC 5V 2A
Size 12.5x8.3x2.5cm
Weight 238g
Hardware
Record File Max 2GB/per file
Record Place Max 140MB/minute, 8.4GB/hour
Multimedia
Audio Format AAC
Video Format AVI, MPEG-4
Decoder Format MPEG4
Resolution Input / Output 720 x 480 (60p), 720 x 576 (50p), 1280 x 720p (50p), 1280 x 720p(60p), 1920 x 1080 (50i), 1920 x 1080 (60i), 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p), 1920 x 1080 (50p), 1920 x 1080 (60p)
Capture Resolution 720 x 480 (60p), 720 x 576 (50p), 1280 x 720p (50p), 1280 x 720p(60p), 1920 x 1080 (50i), 1920 x 1080 (60i), 1920 x 1080 (24p), 1920 x 1080 (25p), 1920 x 1080 (30p)
Record Quality Max 18Mbps@1080P 30fps
Package Include
Package Contents 1 x HDMI cable
1 x User manual
1 x Remote Controller
1 x Power Adapter
1 x Video Cable
1 x CD
1 x Video Capture
Package Weight
One Package Weight 0.63kgs / 1.38lb
Qty per Carton 20
Carton Weight 12.70kgs / 28.00lb
Carton Size 44cm * 24cm * 34cm / 17.32inch * 9.45inch * 13.39inch

Guaranty High Quality And Brand New
What You See Is What You Get
