Item Descriptions:

color:

Sand camouflage

Camouflake pattern transceiver 2nd bullet!

Specific low power transceiver "MSE - 20SC" debut!

The specified low-powerless transceiver has a narrow communication range and is specialized for local use.

It is the best radio for use in limited areas such as urban areas, factories, warehouses, and event venues.

But, this transceiver only does not want to be limited to business use.

By daringly making coloring a pop urban camouflage, we encourage demand outdoors other than business use.

It will be an ideal dish for in-vehicle traveling by multiple vehicles, camping, etc. in connection with family and friends in the mountains and the ocean, and instructions for operations in the saver bag.

It is you who decide how to use!

■ Sand Camouflage

It adopts a sand camouflage pattern that makes special forces in the desert.., Ideal for survival games as well.

■ License / no qualification required

Because amateur radio etc licenses are unnecessary, anyone can use it.

Also, because it is a set of two, you can communicate immediately.

■ 20 channel model

It is possible to communicate with 9ch, 11ch and 20ch models including specific low power transceiver made by other companies.

(Channel settings may vary.)

■ 38 group mode

When using the same channel simultaneously with other groups, it is difficult to communicate with each other by mixing the calls of each other.

By using this group function, you can comfortably talk only in the same group.

■ VOX (Hands Free) Function

In response to voice, you can send it automatically by talking to the microphone without pressing the send button.

Because the belt clip and tie-pin type earphone microphone are set, it is convenient because you can talk hands-free.

■ APO (auto power off)

If the receiving state is not set for the set time (1 hour to 6 hours), and the operation is not performed, the power is turned off automatically.

There is no worry about forgetting to turn off the power supply.

■ Operation for a long time

Operated for about 60 hours with AA alkaline batteries (Usage status, varies depending on batteries.)

Ministry of Internal Affairs and Communications

It is based on communication rules in Japan.

■ Other

Key tone function, key lock function, Velcor function, battery remaining indicator

■ Specification

Model number: MSE-20SC

Total reception frequency: 422.050 to 422.300 MHz (12.5 KHz step)

Radio wave format: F3E

Transmission output: 10 mW

Reception sensitivity: -14 dBμ or less (12 dB SINAD)

Reception system: Double super heterodyne system

Power supply voltage: DC 3.6 to 4.5 V (3 AA alkaline batteries × 3 sold separately)

Consumption current: About 50 mA at reception standby

Maximum reception: approx 140 mA

About 70 mA at transmission

Operating temperature range -10 ° to + 50 °

Size: width 58 × height 103 × depth 28 mm (not including protrusions)

Weight: About 180 g (including AA alkaline batteries)

Color: sand camouflage

Accessories: Earphone microphone × 2, belt clip × 2

Approximate communication distance City area: Approximately 100 ~ 200 m / well-prospective suburbs: 1 ~ 2 km

Features:

• Please enter model number Confirm this is compatible:
• [License / qualification unnecessary] Because a license such as amateur radio etc is unnecessary, it can be used by anyone.
• Also, because it is a set of two, you can communicate immediately.
• 【VOX (hands free) function】 Even if you do not press the send button, it will be sent automatically only by talking to the microphone.
• Because the belt clip and tie-pin type earphone microphone are set, it is convenient because you can talk hands-free.
• 【20 channel model】 It is possible to communicate with 9ch · 11ch · 20ch models, including specified low power transceiver made by other companies.
• (Channel settings may vary.)
• 【Long time operation】 Approx 60 hours operation with AA alkaline batteries (Usage status varies depending on batteries.)
• [APO (auto power off)] When the reception state is not set for the set time (1 hour to 6 hours), and the operation is not performed, the power is turned off automatically.
• There is no worry about forgetting to turn off the power supply.

Product information:

Shipping Weight: 503 g

Package Dimensions: 5.99 x 16.00 x 21.89 cm
