Product Description

Power section

Range of voltage adaptation: 220V AC/50~60Hz
Power Consumption: <5W
Performance and interface section
Format: RGB(Analog),HV(TTL)
Bandwidth: 500MHZ/3dB
Electrical Level: 0.5-2.0Vp-p
Impedance: 75Ω
TTL: 5V, High resistance
Gain: 0dB
Switching speed: 200nS(Max.)
Crosstalk: -52dB@30MHZ
interface: 15HDF or 5BNC
Protection level
Electrostatic protection of the whole machine:
1a Contact discharge level 3
1b Air discharge level 3
Implementation of standards: IEC61000-4-2
Operating environment
Operating temperature: 0~50℃
Storage temperature: -20℃~70℃
Humidity(No condensation): 0~95%
Reliability
Mean time between failures (MTBF): >20000 hours
