Technical Specifications

Picture/Display

Display LED Full HD Diagonal screen size (metric) 107 cm Diagonal screen size (inch) 42 inch

Panel resolution 1920x1080p Aspect ratio 16:9 Picture enhancement

Digital Crystal Clear

100 Hz Perfect Motion Rate

Viewing angle 176º (H) / 176º (V)

Connectivity

Number of HDMI connections 2 Number of component in (YPbPr) 1 Number of AV connections 2

Number of USBs 2 Other connections

Antenna IEC75

PC Audio In (3.5mm)

Analog audio Left/Right out

Headphone out

PC-In VGA

Tuner/Reception/Transmission

Aerial Input 75 ohm coaxial (IEC75) Video Playback

NTSC

PAL

SECAM

Analog TV

NTSC

PAL

SECAM

Dimensions

Box depth 152 mm Box height 667 mm Box width 1165 mm Set Depth 78 mm Set Height 565

mm Set Width 969 mm Set depth (with stand) 235 mm Set height (with stand) 625 mm Set width (with stand) 969 mm Product weight 10.5 kg Product weight (+stand) 13.0 kg

Weight incl. Packaging 15.5 kg

Compatible wall mount adjustable 300 x 200mm

Smart Interaction

Ease of Use One-stop Home button Firmware upgradeable Firmware upgradeable via USB Screen

Format Adjustments

4:3

Widescreen

Subtitle Zoom

Sound

Output power (RMS) 16W (2 x 8W) Sound Enhancement

Virtual Surround

Auto Volume Leveller

Bass Control

Multimedia Applications

Video Playback Formats

Containers: AVI, MKV

H264/MPEG-4 AVC

MPEG-1

MPEG-2

MPEG-4

Music Playback Formats

M4A

MP3

Picture Playback Formats

JPEG

BMP

PNG

Supported Display Resolution

Computer inputs up to 1920x1080 @ 60Hz Video inputs

24, 25, 30, 50, 60 Hz

up to 1920x1080p

Power

Mains power AC 100V-240V, 50/60Hz Ambient temperature 5 °C to 40 °C Standby power

consumption < 0.5 W Power consumption 98 W A
