Item Descriptions:

Product introduction

● Linear PCM recorder with 24bit 96kHz ● Up to 128GB microSDXC card can be used ● Sound pressure 120 dB SPL ● Peak reduction function automatically setting the optimum level ● Variable playback speed ● Playback equalizer ● Wi - Fi remote control,

File transfer, monitoring support ● XY style stereo microphone installation ● Touchless recording ● After recording ● from the spot to SNS ● Overdubbing ● Reverb effect ● Supports 4 track input

From Amazon

Handy recording more freely.

Linear PCM recorder with X - Y system stereo microphone supporting 4TR / XLR input compatible with full remote control on Wi - Fi and file transfer.

A next-generation model realizing full remote control, playback monitoring, file transfer by Wi-Fi has appeared in the linear PCM recorder DR series which has been very popular since its launch.

Together with ease-of-use and redesigned user interface, it overturns common sense of Handy Recording.

DR-22WL is a simple model pursuing an easy-to-use user interface so that anyone can easily enjoy high-sound linear PCM recordings.

It is an ideal model for music recording with acoustic instruments as medium, such as orchestral instrument, piano, acoustic guitar.

High sound quality recording with only the main body - Full-featured X-Y system stereo microphone mounted -

X-Y method unidirectional stereo condenser microphone realizing aimed recording

Expanding

Mount a unidirectional condenser microphone in a microphone capsule designed taking acoustic characteristics into account.

Mike unit was selected through listening evaluation, while taking the sound quality of the popular equipment as a standard.

It adopts the X - Y method which can obtain a sound with a stereo feeling while having a coherent sound.

Sound pressure 132 dB Reliable for high volume sound recording with soundproof high pressure resistant to reliably capture large volume of SPL

Recording at the rehearsal studio, recording of the rock concert, airplane, train etc. It is designed to be able to record without distortion even with a large volume sound source.

132 dB SPL is a loud volume that exceeds 20 times the maximum sound pressure of 105 dB SPL of a general cinema.

Shock mount structure to reduce physical noise

Expanding

Like a condenser microphone used in a recording studio, it has a shock mount structure that absorbs vibration.

The rubber material provided between the capsule and the main body effectively absorbs vibration.

Dual level recording function to prepare for over level

In digital recording, adjusting to be able to record with the largest possible sound leads to high resolution recording.

On the other hand, if you become distorted, you can not use the file.

Dual level recording is a function to solve both requests and simultaneously records two stereo files of different levels.

If it gets distorted, you can use files recorded at a lower level (files that are not distorted).

* When dual level recording is enabled, the maximum simultaneous recording track is 2 tracks.

XLR / TRS input terminal to meet professional requirements

+ 4 dBu line level / enabling external microphone / external device connection / + 48 V phantom compatible XLR / TRS input

Expanding

Two external input terminals with NEUTRIK made XLR / TRS combo jack are equipped.

Since it corresponds to + 4 dBu input, connection with professional equipment such as PA console is also possible.

In addition, condenser microphones can also be connected to support phantom power supply.

The XLR connector has a locking mechanism indispensable for business use.

Adoption of PGA and high performance audio codec realizes low noise

Expanding

PGA (Programmable Gain Amplifier) ​​is adopted for level adjustment of audio input circuit.

Although it is common to adjust the level using the level adjustment circuit of the audio codec, we realized the low noise audio input circuit by making the level adjustment circuit independent.

In addition, the audio codec adopts the famous CIRRUS LOGIC high sound quality codec, CS 42 L 52.

Body microphone and external input both go through this low noise audio input circuit.

4-track recording convenient for use with external microphone and external input

Expanding

You can record different stereo sound sources simultaneously, such as built-in microphone + PA console output, built-in microphone (off-microphone) + external condenser microphone (on-microphone).

Each input level can be individually set.

Even for stereo recording, you can individually set L / R, or 1/2 input levels.

After recording, you can adjust the level and mix down to a stereo file.

Low noise recording without touch noise

Access pointless, one-to-one Wi-Fi connection

Expanding

The Wi - Fi connection connects a Wi - Fi device such as a smart phone to the DR - 44WL one - to - one, so you do not need an external Wi - Fi access point.

You can establish a Wi-Fi connection simply by entering the information displayed on the screen.

You can check the connection status on the main unit LED, application display screen.

Even if the connection is blocked, the recording will not stop.

Full remote control with free application (iOS / Andoroid)

Expanding

Touch noise during operation is regarded as an unavoidable problem in handy recording.

To eliminate this, the only solution is to not touch the main body.

Since DR-44WL can control wirelessly from the application, touch noise can be eliminated.

Not only transport controls such as recording and playback, you can operate wirelessly up to the input level adjustment and low cut filter setting.

It also features a power saving mode to reduce battery consumption by Wi-Fi transmission / reception.

* Functions that affect radio operability undesirably are excluded from control subjects.

Voice confirmation also wireless, wireless playback monitoring function *

With conventional remote control, voice can not be confirmed even if operation can be done.

DR - 44WL realizes wireless playback monitoring that allows you to record recorded sound via Wi - Fi and hear it from smartphone.

Just like connecting earphones to the DR - 44WL, you can check the voice while setting it in a location out of reach.

* Wireless playback monitoring function is a function assuming sound confirmation after recording.

It does not support real-time monitoring of input sound.

After recording, go from the spot to SNS via smartphone

Dual format recording function that can simultaneously record WAV / MP3 files

It is a function to record uncompressed WAV file and MP3 file at the same time.

You can get uncompressed sound source and compressed sound source without converting work.

* It is limited to the combination of WAV (16bit, 44.1k / 48k Hz) and MP3 on the specification of the MP3 file.

It can not be used for 24 bit and 96 kHz WAV / BWF files.

Audio file sharing service From SoundCloud to SNS

Expanding

After recording, select the file saved in the main body from the dedicated application and wirelessly transfer it to the smart phone.

You can upload directly to SoundCloud from the application after transfer.

In SoundCloud you can share it on facebook, twitter, Google + timeline by one button.

A SoundCloud account can be created for free and you can upload up to 2 hours of playback time.

* Smart phones must be compatible with Wi-Fi connection.

You can not connect to other Wi-Fi networks because it is a one-to-one connection while connected.

* When uploading to SoundCloud, smartphone needs to be connected to the Internet.

Wireless transfer of files to PC

Expanding

Wireless transfer not only to the smart phone but also to the personal computer.

You can transfer the specified file using the free dedicated transfer application "DR FILE TRANSFER".

Of course, Windows and Mac applications are available.

You can download from the TASCAM website.

* The PC must be compatible with Wi-Fi connection.

You can not connect to other Wi-Fi networks because it is a one-to-one connection while connected.

Multiple automation functions that can simplify operations

Level adjustment function (peak reduction, limiter) to automatically set the optimum level

The level is automatically controlled according to the situation of the input sound.

The peak reduction function that automatically lowers the level when an excessive input is detected is ideal for music recording.

The limiter suppresses excessive input without changing the input level.

Various auto track increment (file update) function that can be set according to the application

Automatically update the file at the specified level or elapsed time and continue recording.

When setting to [5 minutes], file updating (splitting) is performed automatically every 5 minutes, which is convenient for long-time recording.

Of course, each file can be reproduced seamlessly even when integrated with waveform editing software etc.

Manual file update is also possible.

Auto Rec function to detect audio input level and start recording automatically

If you set it before the concert starts, recording will start automatically with voice detection.

Auto mark function that can be marked automatically according to the set conditions

When the specified level is detected, or you can manually mark a file (mark) on the file.

If you set it to level, you can mark it automatically for each place where the song ended.

Automatic divide function to automatically split files at mark location * Auto divide function *

It is a function to divide files at places marked.

By using it together with the auto mark function, you can automatically divide files that have been recorded for a long time for each song.

Of course it is also possible to split manually.

Making full-scale music using MTR mode

MTR mode that can be utilized for music production as well as single MTR

This mode allows you to record four tracks individually.

With the built-in microphone, you can record multiple times without preparing a microphone.

Since it corresponds also to external input, it corresponds also to the connection of the amp simulator and the keyboard, as well as the vocal recording by the external condenser microphone.

As the recorded sound source can mix down, you can produce a stereo master with only DR - 44WL.

Reverb effect with vibrant and instrumental performances cleanly

The reverb effect is useful when you perform on-mic recording of a single instrument or vocal.

It has basic presets such as halls and rooms so you can use them according to your songs.

Effects can be applied during recording or playback.

Features:

• Please enter model number Confirm this is compatible:
• Manufacturer model number: DR-44WL

Product information:

Shipping Weight: 793 g

Package Dimensions: 10.67 x 20.57 x 27.18 cm
