Product Description

Feature:
There are 4 pins out of the module: VCC , Trig(control side), Echo(receiver),out (empty) GND .So it's a very easy interface for controller to use it ranging.
The all process is : pull the Trig pin to high level for more than 10us impulse , the module start ranging ; finish ranging , If you find an object in front , Echo pin will be high level , and based on the different distance,it will take the different duration of high level. So we can calculated the distance easily:
The test distance = (Duration of high level * speed of sound (340M/S))/2

Module details:
Voltage: DC5V;
Static current: Less than 2mA;
Output signal: Electric frequency signal, high level 5V, low level 0V;
Sensor angle: Not more than 15 degrees;
Detection distance: 2cm-450cm;
High precision: Up to 0.3cm;

Package includes:
5* HC-SR04 Ultrasonic Distance Sensor
1*HC-SR04 Bracket
1*Male to Femal jump wires 20pin
10*cable ties for fixing HC-SR04

Feature

Update new version: Add 3 items as gift: 1*HC-SR04 Bracket + Male to Femal jump wires 20pin +10*cable ties for fixing HC-SR04
Ranging distance: 2cm~450cm.High precision: up to 0.3cm.Effectual angle:15 degree.Module precision:blind spots (2cm)-SUPER CLOSE
Power supply :5V DC. Quiescent current : <2mA.Size : 4.5 x 2.5 x 1.5 cm / 1.8x 1 x 0.59inch (L*W*T)
Automatically send eight "40 kHz "and detect whether there is a pulse signal back.
Mode of connection:4 pins VCC, Trig (control side), echo (receiver), out (empty),GND
Brand : Kuman
Item model num : K18-Distance M-US-5pcs
MPN(PartNumber) : K18-Distance M-US-5pcs
Product Dimensions(LxWxH) : 10x7x8cm ; 113 g
Package Dimensions(LxWxH) : 10x8x7cm ; 113 g
