Item Descriptions:

size:

HDMI TO HDMI + Audio (SPDIF + L / R)

HDMI audio separator

Enjoy high sound quality and high image quality on large screen

If you connect it, it's easy to connect at the end!

There is no speech delay without deviation and you can enjoy with a better realistic feeling.

You can now watch large screen movies by connecting the HDMI input of the projector and the optical terminal of the speaker amplifier.

Supported models: PS3, PS4, Chromecas, Blu-ray Player, Xbox, Fire TV Stick, WiiU, Apple TV etc.

Product specification

Product name: HDMI to HDMI SPDIF + R / L Coverter

Input port: 1 * hdmi (PS3 / PS4 / Blu-ray player / cable box / Apple TV etc.)

1 * DC 5 V (power adapter)

Output port: 1 * hdmi (projector / hdTV / monitor)

1 * SPDIF / optical fiber digital (amplifier / speaker)

2 * RCA / stereo analog (earphone / speaker)

Supported resolutions: 24/50/60 fs / 1080 p / 1080 i / 720 p / 576 p / 576 i / 480 p / 480 i

Input resolution: 1080 P (50/60 Hz) / 720 P / 480 P

Power adapter input: AC 100 V - 240 V (50/60 Hz)

Power supply output: DC 5 V / 1A

Input cable length: ≤ 15 mAWG 26 HDMI standard cable

Output cable length: ≤ 20 mAWG 26 HDMI standard cable

Maximum bandwidth: 225 MHz

Maximum baud rate: 6.75 Gbps

Input / output TMDS signal: 0.5 - 1.5 Volts PP (TTL)

Input / output DDC signal: 5 Volts PP (TTL)

Maximum operating current: 500 mA

Working temperature: -15 to + 55 ° C

Operating humidity: 5 to 90% RH (noncondensing)

Connection order

Connect the HD device to the HDMI input port of the product with the HDMI cable.

Connect the HD display to the HDMI output port of the product with the HDMI cable.

Connect the audio equipment to the R / L port of the product with the audio cable.

Please connect the amplifier etc. to the SPDIF port of the product with a leased line.

Please turn on the power with the AC adapter.

Product improvement

1. Indicator light: We changed the lamp because there are many complaints from customers saying "dazzling".

2. Select the power cable to be used for PSE certification instead of the general power cable.

Moreover, it does not raise.

3. Since it is difficult to use the switch, it was remodeled so that it can be output in whatever way you choose to reach the purpose easily.

Please acknowledge it.

In case

Recommended use case

1. I normally use a TV speaker, but I want to use a dedicated audio system when watching movies etc.

It is a grateful mechanism in theater format.

2. Since you are using a monitor without audio output, you want to output the audio signal separately to an external amplifier, external speaker, etc.

3. It can also be used for speakers with HDMI port

4. It can be conveniently used for extracting only audio parts of concert videos, rakugo or reading aloud, various video images, and making sound only data.

5. When separating video / audio separately to old projector and AV amplifier not compatible with HDMI voice, etc.

please note:

1. It can support HDMI 1.3, it can not correspond to HDMI 1.4.

2. It can handle 3D video.

It can correspond up to 3.1080p, it can not correspond to 4K or 2K.

4. ARC correspondence is not possible.

5. Please put the power supply last.

6. If power is supplied from a part of the HDMI equipment, power supply is unnecessary.

But I do not recommend it because it is bad for HDMI equipment because it is unstable.

7. If the personal computer HDMI terminal is an input only terminal, it can not be output by connecting from the personal computer and can not be watched (conversion adapter to miniHDMI of Handycam must be purchased separately)

8. If you have a Super Nintendo Entertainment System or GameCube AV Cable etc., please ask for a converter that switches AV output to HDMI.

9. SPDIF output can output 5.1 CH audio such as Dolby Digitla 5.1 CH and DTS 5.1 CH,

※ Dolby Digital Plus and PCM 5.1 CH (and more types as well) can not be output.

This unit can not change the format of the input signal, the output signal follows the input signal.

In other words, if you input 2 ch, switch to 2 ch mode and output 2 ch audio. If you enter 5.1 ch, switch to 5.1 ch mode and output 5.1 ch audio.

The main body of the product is CE, FCC and ROHS certified, please rest assured!

1 year manufacturer's warranty

This product comes with 1 year manufacturer's warranty from date of purchase.

If you need consultation about products and use, exchange or repair your use, please contact <[email protected]> directly.

Specialized staff will respond quickly.

Features:

• Please enter model number Confirm this is compatible:
• It is an HDMI distributor that can separate HD video and audio from HD source.
• PS3 / PS4 / Blu-ray Disc / cable box / apple TV / IP This is for extracting audio from the HD source of equipment such as TV.
• With optical / coaxial digital output, you can listen to the sound with equipment such as speakers and headphones without HDMI input.
• The HDMI splitter has three types of audio modes, PASS / 2.0 CH / 5.1 CH, and the power supply instruction light is also attached.
• Compact size, you can transfer ultra high-quality video as it is with simple connection of only one HDMI cable.
• It corresponds to 3D image · high definition image of full Hi-vision.
• Since all cables can be arranged in the same direction, it can be installed cleanly.
• Since it has an HDMI input port on the front, it is possible to optimally arrange for devices that frequently detach.

Product information:

Shipping Weight: 408 g

Package Dimensions: 7.01 x 15.19 x 19.41 cm
