Features:



11N wireless technology， 300Mbps wireless speed

2x2MIMO architecture， CCA technology to enhance wireless stability， expand wireless coverage

QSS fast security settings， wireless network more secure， more efficient set

IP bandwidth control functions， the free allocation of network bandwidth users

WDS wireless bridging function， easy to expand the wireless network

Parental controls， flexible control of the child or employee online behavior





Strong wireless performance



TL-WR840N using 11N wireless technology， wireless transmission rates up to 300Mbps， compared to traditional 54M 11G and 150M products to meet more wireless client access， in the same number of wireless clients to provide more for each client wireless high-bandwidth data transmission within the LAN more efficient， while higher wireless bandwidth can also avoid congestion data， reducing network latency， making voice and video， online on-demand， online games more smoothly.







TL-WR840N using 2x2 MIMO (Multiple input multiple output) architecture， multi-channel transceiver radio signals， improve signal penetration， increasing wireless coverage than single antenna wireless products provide higher wireless performance and stability.









TL-WR840N also used the CCA (Clear Channel Assessment) empty channel detection technology， when it detects the surrounding wireless signal interference， it can automatically adjust bandwidth mode to avoid channel interference， make wireless signals more stable. When the interference disappears， can be automatically tied idle channel， make full use of the advantages of channel bundling， enhance wireless performance.







Multi-level security



TL-WR840N support SSID hidden， wireless MAC address filtering， 64/128/152 WEP encryption and WPA-PSK / WPA2-PSK， WPA / WPA2 security mechanism to protect the wireless network will not be violated or theft.



The TL-WR840N the QSS quick and safe setting function， with the wireless card has QSS or WPS function use， simply press the QSS fast security buttons respectively router and network card， or enter router PIN code on the computer， to complete WEP encryption is more secure than the traditional level of WPA2 wireless security connection， no need to remember complex passwords.













Wealth of useful features



TL-WR840N with IP bandwidth control feature， you can assign each computer's Internet bandwidth according to the needs of different users， the Internet， avoid the use of individual users BT， Thunder and other software take up too much bandwidth， affect other users normal?  bridal veil gown disrespect?









TL-WR840N also has WDS wireless bridging capabilities that enable wireless bridge between two or more wireless router， expand wireless coverage， the bridge but can also support AP mode provides wireless access to meet the long-range， multi-floor or dormitory wireless environment， coverage requirements.









TL-WR840N supports parental control function， can for the children from Monday to Sunday at different learning requirements， set different periods and website access restrictions， let the children stay away from bad sites Health Internet; access control functions and can be different according to the company employees Internet needs， set different access permissions and access to the website， so that employees work more efficiently， manage more humane.















Product Specifications:



Hardware Specifications



Protocol Standards



IEEE 802.11n， IEEE 802.11g， IEEE 802.11b;

IEEE 802.3， IEEE 802.3u;

Wireless rate



300Mbps

Interface



4 10 / 100M adaptive LAN ports support auto-flip (Auto MDI / MDIX);

A 10 / 100M adaptive WAN port， auto flip (Auto MDI / MDIX);

Button



QSS / Reset button reuse

LED



SYS system instructions;

WLAN wireless status indicator;

Each port Link / Act instructions;

Antenna



Two external fixed omni-directional antenna

Size



158mm x 120mm x 34mm (L x W x H)

Wireless Parameters



Basic functions



Wireless switch;

SSID broadcast switch;

Channel selection: 1-13;

Optional frequency bandwidth: 20MHz， 40MHz， automatic;

Wireless Mode Optional: 11n only， 11 bgn mixed， 11 bg mixed， 11g only， 11b only;

Transmit power adjustable: high， medium and low





Operating Mode



AP mode;

WDS wireless bridge mode;





Wireless Security



Wireless MAC address filtering;

Wireless security function switch;

64/128/152 bit WEP encryption;

WPA-PSK / WPA2-PSK， WPA / WPA2 security mechanism;

QSS fast security settings





Other features



Support wireless roaming;

Radio host status display;

Wired function







Practical function



IP bandwidth control function;

Parental controls， Internet control;

Peanut shell DDNS;

Network Settings



WAN port connection type automatically detected;

WAN port connection type support: PPPoE， Dynamic IP， Static IP， L2TP， PPTP;

Dial-up Type: Automatic dialing， on-demand dialing， manual dialing， timing function;

MAC address modification and cloning;

VPN Pass-through;

Static routing;

DHCP settings



DHCP server;

DHCP client;

Client list;

Static address assignment;

Port Forwarding



Virtual Server;

Special applications;

DMZ host;

UPnP settings;

Security Settings



IP and MAC address binding against ARP attacks;

IP address filtering;

Domain filtering;

MAC address filtering;

DoS attack prevention;

FLOOD attack prevention;

Ping packet control;

System Tools



Traffic statistics;

System security log;

Mail alert;

Local Web management control;

Remote Web management;

Import and export configuration files;

Web software upgrades;

Other



Packing Accessories



11N Wireless Broadband Router TL-WR840N;

Power adapter;

User Manual;

Warranty card;













Environment



Operating temperature: 0 ℃ to 40 ℃;

Storage temperature: -40 ℃ to 70 ℃;

Humidity: 10% to 90% RH non-condensing;

Storage humidity: 5% to 90% RH non-condensing;
