Item Descriptions:

color:

blue

Product introduction

【Features of Varieques】

1. Just start the button just by pressing the button, operation is also easy.

2. The suction force can be adjusted in two stages.

3. Auto power off function in 30 seconds

4. The nozzle parts can be removed, washed with water, boiled and disinfected.

5. When the remaining battery power is low, the power indicator lights up.

● Generic name

Motorized portable aspirator

● Contraindication / Prohibition

【warning】

· This product is a dedicated instrument for removing secretions and mucus (runny nose) inside the nostrils, so do not use for other purposes.

· Do not use if sick in the nostrils, scar, bleeding or inflammation.

· If there is a nose disease in the subject to be applied, consult a doctor about use / disappearance of this instrument and use it.

· Do not store this product in newborn or infants' reachable area.

[Because there is a danger of nozzle erroneous drinking]

[Contraindication / Prohibition]

· Do not wash the main body with water or liquid.

[To cause electric shock or malfunction]

· Do not use, store, repair, remodel, adjust, etc. in a situation that does not satisfy the usage conditions indicated in the specifications of this product and precautions for use.

[To cause injury or malfunction]

● Item specifications

【Body size / weight】

· Dimension: height 103 × width 78 × height 107 (mm), tolerance ± 10%

Weight: 170 g (battery not included)

【Ingredients (part in contact with the body)】

Silicon nozzle (silicone)

Side stopper (silicone)

Body (ABS resin)

Power button (ABS resin)

[Other specifications etc]

Suction pressure: -60.0 kPa ± 10%

· Pump exhaust flow rate: 2.5 L / min or more

Durability against the internal fracture of the suction container: Maintain the function as a suction container and do not permanently deform or break it.

· Number of times of driving: 840 times (when driving for 10 seconds with no load, depending on company data)

· Operating environment: + 16 to + 35 ° C, ≤ 85% RH (no condensation)

● Usage Notes

(1) Important basic attention

· Do not use continuously for more than 30 seconds.

[Because there is a danger of hurting the mucosa]

· When sharing with more than one person, use a new silicon nozzle or do boiling disinfection without fail.

[Because of fear of infection]

(2) Usage notice

· If symptoms such as rash, redness, itching, etc. appear during use, stop using it immediately and consult a doctor.

· Place the main body, accessories, batteries etc in places that children and infants can not reach.

[There is a danger of accidental ingestion or injury]

· Do not let children use it.

To be operated by an adult.

[There is a fear of injury]

· Do not drop the main unit.

[Cause failure, malfunction etc]

· Do not remove main body screws and rubber parts.

[There is a possibility of giving a shock]

· Do not disassemble, repair, or remodel the main unit.

[Cause failure, malfunction etc]

· Do not use if damage, malfunction or abnormality is suspected on the main body.

Also, if they occur during use, discontinue use immediately.

[Causes injuries, malfunctions, defects, etc.]

· Do not wash parts with thinner, solvent, solvent, etc.

[Cause deformation of parts, cause discoloration, etc.]

Information on Manufacturers and Manufacturers (Inquiries on Products)

【Manufacturer / seller】

JCT Corporation

〒731-0138

Hiroshima Prefecture Hiroshima-shi Anzanami-ku Gion 1 - chome 28 - 7

082-850-3210

【Foreign Manufacturer】

Living Lab Co., Ltd.

● Electrical Rating

· Power supply: AA size (1.5 V) alkaline dry cell × 2

· Power supply voltage: 3 VDC

Power consumption: 1.5 W

· Protection form against electric shock: internal power supply equipment

· Degree of protection against electric shock: BF type mounting part

· Electromagnetic compatibility (EMC standard): conforming to EN 60601-1-2: 2007.

· Protection grade by outline of electrical machinery and equipment: IP 22

Usage notes

Please refer to the instruction manual always.

Features:

• Specific management medical equipment Medical equipment certification (approval) number: 228APBZI00002000
• [Body size] 103 mm × 78 mm × 107 mm (length × width × height)
• Contents: Main body, 1 nozzle of silicon nozzle (narrow tip), 1 O ring, 1 cap, instruction manual, package insert, quick manual, 2 AA alkaline batteries
• Product specifications · Batteries used: AA alkaline batteries (2) · Suction pressure: -60.0 kPa ± 10% · pump exhaust flow rate: 2.5 L / min or more · Dimensions: length: 103 mm, width: 78 mm, height:
• 107 mm (when fitted with cap) Weight: 170 g (without batteries) Number of uses: 840 times (no load, driving for 10 seconds) Operating environment: +16 to +35 ℃, ≤ 85% RH
• Thing) · Target age: 0 years old ~
• Easy aspiration of a baby's snot with a single button! Suction force can be adjusted in two steps according to the condition of runny nose

Product information:

Shipping Weight: 381 g

Package Dimensions: 10.49 x 12.50 x 15.01 cm
