Product Description

Each DMX common controller occupied 3 DMX address, adopt coding switch is setting DMX original address code from 1 to 9, 1 is the lowest, and 9 is the highest , 511 address code could be setted in all. This DMX common controller adopts the advanced
micro control unit, receives standard DMX-512 digital control signal and transformed it into PWM signal to driving LED
With over 30 preprogrammed color changing patterns, including gradual changing, screening and jumping, our DMX controller offers a variety of display options.. As a powerful color managing controller, it will enable you to choose the desired pattern and appropriate speed to manage your RGB LED lighting fixtures.With 0 to 100 dimming grades, you can also control the color and brightness according to your requirements easily, and mix up to 1 million different colors.The LCD monitor on the controller offers an easy and visible managing method; the mounting bracket will enable the operator to easily fix the controller onto any place.
>>>Specifications:
-Working temperature: -20 to +60 centigrade
-Output: 3 CMOS drain-open output
-Connecting mode: common anode
-Input Voltage: 12~24V DC
-Output Current:<8A(each circuit)
_Output Power:8A -5V:<120W, 12V:<288W, 24V:<576W (3 circuit)
-Static power consumption:<1W
-Product size: L166*W67*H41mm
-Net weight: 340g
>>>Application: This controller gives any uses full lighting manipulation to meet almost all applications need by allowing users to control all colors, hue, and brightness of the RGB strip light.

Feature

Input 12V, working current 24A / 3 channels
Decoder is designed to convert the universal standard DMX512/1990 signal into analog signal to control our RGB Flex Strips
User addressable DMX interface-with easy dip-switch settings and testing modes
High power output, 3 output channels, 8A per channel
DMX pass through and in/out connector for daisy chain configurations
Brand : JOYLAND
MPN(PartNumber) : DMX512-3BX
EAN : 0709803611580
Product Dimensions(LxWxH) : 17x7x5cm ; 386 g
Package Dimensions(LxWxH) : 19x9x6cm ; 386 g
