Item Descriptions:

Product introduction

Reading range: Readable range: 203.2 × 127 mm Reading resolution: Max. 0.005 mm Reading accuracy: ± 0.25 mm (pen) Readable height: 10 mm (pen) Pen Pressure level: up to 2048 level inclination detection level:

60 level reading speed: Up to 200 points / second (Bluetooth 2.1 / 2.0 + EDR / USB).

Wireless range: Approx. 10 m Wireless Continuous use time: 8 hours or more (when the function display is lit).

Charging time: 6 hours.

Supply voltage / current consumption: 5 V / maximum 500 mA.

Power supply: Rechargeable lithium ion battery / USB.

Interface compliant standard: Bluetooth 2.1 + EDR / USB

From Amazon

Value added wireless.

To the comfort which can not be confirmed by anything

Realize a clear work space that does not get caught on cables, allowing for a free working style.

It can be connected easily to a personal computer equipped with Bluetooth function and can be used in a relaxed posture in about 10 m range.

For ease of use and comfort, Bluetooth wireless.

Realize a clean work space that is not bothered by cables, allowing for a free working style.

It can be easily connected to a computer equipped with Bluetooth function and can be used in relaxed attitude in the range of about 10 m *.

* Wireless range varies depending on usage environment.

Wireless range may be narrowed in the vicinity of equipment that may cause radio disturbance such as microwave ovens, cordless phones, and wireless network equipment.

Hybrid communication & USB charging

If you connect with the computer with the included USB connection cable, you can communicate with USB and charge it into the built - in rechargeable Li - ion battery.

If you can not connect with Bluetooth, you can continue creative work without interruption.

* It is also possible to connect the USB connection cable to a commercially available USB AC adapter and charge it from the AC outlet.

Charging time 6 hours

Continuous use

8 hours or more when the function display lights up

18 hours or more when the function display is off.

Required system

■ Windows

Equipped with Bluetooth 1.2 or higher ※ 1 or USB port Standard equipment * 2 DOS / V machine, NEC PC 98 - NX * 3

Windows 7 / Vista / XP (Service Pack 2 or later) (including 64-bit version)

CD-ROM drive

■ Macintosh

Equipped with Bluetooth 1.2 or higher * 1 or USB port as standard equipment * 2 and PowerPC G4 or higher or Macintosh with Intel processor

Mac OS X 10.4.8 or later

CD-ROM drive

* 1 For computers not equipped with Bluetooth function, a Bluetooth adapter is required separately.

* 2 Since it consumes up to 500 mA of current, connect it to the USB port that is standard equipment in the computer.

* 3 Operation is not guaranteed on a computer with built-in tablet function.

basic specifications

· Reading range: 203.2 × 127 mm

· Reading resolution: maximum 0.005 mm

· Reading accuracy: ± 0.25 mm (pen)

· Reading speed: Up to 200 points / second (Bluetooth 2.1 / 2.0 + EDR / USB) Up to 133 points / second (other than Bluetooth + EDR)

· Writing pressure level: up to 2048 levels *

· Level detection level: Up to ± 60 levels

· Power supply: Rechargeable lithium ion battery / USB

· External dimensions: about 363 (W) × 253 (D) × 15 (H) mm

· Weight: about 0.9 kg

· Interface compliant standard: Bluetooth 2.1 + EDR / USB

* For Windows, the 2048 level writing pressure function is effective only with the corresponding application software.

The initial setting of the writing pressure function of the driver is 1024 level, and it is necessary to change the setting of the driver when using with application software compatible with 2048 level writing pressure function.

For Mac OS X, application software automatically supports 2048 level writing pressure function.

Features:

• Please enter model number Confirm this is compatible:
• Bus: USB

Product information:

Shipping Weight: 2081 g

Package Dimensions: 9.30 x 34.19 x 46.99 cm
