Cisco 90 Series Switches Offer:
- High-performance capabilities: With powerful network performance at an affordable price, you can give your network a boost of speed and capacity to support bandwidth-intensive applications.
- Support for advanced technologies: Built-in quality of service (QoS) intelligence on all models helps maintain consistent network performance and keeps your applications running smoothly.
- An eco-friendly solution: Optimizes power usage to be energy efficient without compromising performance.
- Affordability: Designed specifically for small businesses that need a basic network with automated features that get you up running in minutes.
- Peace of mind: All Cisco 90 Series switches are protected for the life of the product by the Cisco Limited Lifetime Hardware Warranty.
- Ease of use: Works right out of the box, there's no software to install and nothing to configure.
Product Specifications
Switching capacity
16 Gbps
Forwarding capacity
11.9 mpps
Head-of-line (HOL) blocking
HOL blocking prevention
Jumbo Frame
9216 bytes
Priority levels
4 hardware queues
Scheduling
Priority queuing and weighted round-robin (WRR)
Class of service
802.1p priority based
Ports
8 RJ-45 connectors for 10BASE-T/100BASE-TX/1000BASE-T ports
Cabling type
Unshielded twisted pair (UTP) Category 5 or better for 10BASE-T/100BASE-TX; 1000BASE-T recommended.
LEDs
System/PWR, Link/Activity, 100M,* Gigabit,*
Standards
802.3 10BASE-T Ethernet
802.3u 100BASE-TX Fast Ethernet
802.3ab 1000BASE-T Gigabit Ethernet
802.3z Gigabit Ethernet
802.3x flow control
802.1p priority
802.3az, Energy Efficient Ethernet
Dimensions (W x H x D)
6.2 x 1.18 x 5.05 inches (160 x 30 x 128.5 mm)
Unit weight
0.46 lb. (0.21 kg)
Power
DC 12V, 1.0A
Certifications
UL (UL 60950), CSA (CSA 22.2), CE mark, FCC Part 15 (CFR 47) Class A
Operating temperature
32° to 104°F (0° to 40°C)
Storage temperature
–4° to 158°F (–20° to 70°C)
Operating humidity
10% to 90%, relative, non-condensing
Storage humidity
10% to 90%, relative, non-condensing
Package Contents
●Cisco 90 Series Switch
●Power cord/power adapter
●Mounting hardware
●Quick-start guide
Minimum Requirements
●Category 5 Ethernet network cable
●TCP/IP, network adapter, and network operating system (such as Microsoft Windows, Linux, or Mac OS X) installed on each computer in the network.
