DAELIM DOBIDOS DB-8500, Toilet Bidet Toilet Seat with remote control 220V Warm Water,Water Proof,Dry function Simple English User's Guide


Bullet Point

Personal Area Cleaning : Can be used by every menber of your family, cleans even the smallest dirt particles.
Warm-Air Drying : Keeps you feeling fresh and clean after use.
Adjustable Pressure : DRy air temperature and water pressure cna be adjusted in five steps.
Remote Controller : Easy view LCD window of it and easy operation for convenient condition checking.
You're buying electronic Goods of 220V.You may need a step up Voltage Converter for 110V(ex, USA,Canada)


Product Features

Function of Produts

1. Personal Area Cleaning : Can be used by every menber of your family, cleans even the smallest dirt particles.
2. Bidet Cleaning : Enhances femine hygiene, especially effective for ladies during menstruation or pregency.
3. Massage Cleaning : The nozzle moves back and forth automatically improving both cleaning efficiency and blood circulation.
4. Adjustable Nozzle Position : Freely repositioned remainer.
5. Warm-Air Drying : Keeps you feeling fresh and clean after use.
6. Self Diagnosis : A built-in microprocessor always checks the status of the device.In case of malfunctions, a light on the panel will blink.
7. Warm Seat : Seat temperature is adjustable, providing the user with their own level of comfort
8. Adjustable Pressure : DRy air temperature and water pressure cna be adjusted in five steps.
9. Adjustable Temperature : Temperature of cleaing water and seat can be adjusted freely.
10. Soft Opening/Closing : Since the seat closes gently without any noise or impact to the seat, you don't have to worry about damaging the seat.
11. Sit-On Switch : Activated when sat on and automatically deactivetes when user stands up.
12. Self Cleaning Nozzle : The nozzle cleans itself before and after every use.
13. Power Saving : When not in use, both water and seat temperature are automatically lowered to pre-heating level minimizing the power.
14. Deodorization : A built in ceramic fliter reduces a smell during toilet use
15. Continuous Warm Water : Not low tank type but continuous warm water supplying type with solenoid valve.
16. Power & Complete cleaning : With the strong water pressure,the cushion-like gentle and soft air bubble helps complete cleaning.
17. Auto function for children : Auto function from washing to drying.
18. User setting : Fix the memories on nozzle position, water pressure, water temperature and seat tempearture for maximum of 4 persons.
19. Remote Controller : Easy view LCD window of it and easy operation for convenient condition checking.


Product Specification

Place of Origin: Seoul South Korea
Brand Name: DOBIDOS
Model Number: DB-8500
Installation Type: Floor Mounted
Spray Type: Horizontal
Power Source: AC120V, 220V / 50~60Hz
Power Consumption: Max. 1310W
Available Water Pressure: 21psi~115psi (1.5~7.5kgf/㎡)
Power Fuse: AC 250V / 6A Power Code: 5.25 ft (1.5m) Water Flow: 0.16gal/min(600cc/min) Water Temperature: Max. 104℉ (40℃)
Heater Capacity: Cleaning - 1250W, Drying - 300W
Seat Type: Elongate
Safety Protection: Protection circuit, thermostat, Thermal fuse, Float switch
